Recel pinball machines are extremely durable. Their only weak point is the MPU card known as “system III”, which is based on a PPS4 architecture that has long since disappeared. But today, this is no longer a problem, since we've managed to clone this card with robust, modern components. No more problems with spider chips or corrupted non volatile memory. With this new card, you've got all the games you need. As a bonus, our famous WiFlip application gives you total control over the machine. Wirelessly, from your computer, you can detect and solve any problems with lamps, contacts, coils or display in the blink of an eye.
Yes, you are not hallucinating, we have successfully cloned our first GPKD 10788. It is avalaible now from this site. As an icing on the cake, we now use Xilinx Spartan 7 series FPGAs to make the cloning. They are literally gorgeous. It is a real pleasure to write VHDL for them. And besides, we added a wifi interface as a very super feature. It will turn your pinball into a wireless device that you can connect to your computer, and let you observe various things about its internals.
PPS4 systems from Rockwell, also called spider chips, have been used in many complex designs, including early U.S. space shuttle. Unfortunately, they vanished from the surface of earth, as time fled by. Then, it became almost impossible to repair such systems. This is no longer true. Here in Vittel, France, we manufacture perfect clones for these little spiders. This is now possible to replace a dead spider chip by our own solution (A1752, A1753, 10696, 10788, etc...). Our products are pin to pin compatible with the original components. It becomes so easy to repair Gottlieb System 1 pinball machines! We are happy to share all the required material to reproduce any PPS4 or PPS4-2 peripheral. You can freely reproduce our solutions on your own, or directly purchase them on the store below. A1752xx, A1753xx and 10696 are currently available. Don't wait.
Order yours now!
What is WiFlip? WiFlip is a new set of features. They come for free with any spider clone of our conception. The main goal of WiFlip is to make your pinball communicating with your computer through wifi. You will be able to diagnose the CPU board by observing various signals from your PC. For example, you can test the switch matrix of the pinball. You may also set the configuration dip switches “digitally“ instead of having to access the real dip switches located inside the pinball. Dispays are duplicated on the PC, in real time! and many other features!
Download an entire project just for free, make yourself the PCB from the provided gerber files and heat up your solder station. You are going to make your first IC.
Download project files
Download the project. Buy the PCB and get a bunch of components from your preferred local dealer. You will make your PPS4 peripheral.
Get my PCBs
Click the reference number of the part you need and we will swiftly make it for you.
That's it.
Add to cart
RS3CLN is an exact replica of the original Recel system III MPU which is used in several Recel pinballs from the 70’s. Dimensions, connections, timings are totally indistinguishable. To make it work in a Recel pinball, just disconnect the 3 connectors (PC, MA, MB) from the old MPU and unmount it from the metallic backbone (unscrew the plastic spacers and the power transistors). Then, mount the RS3CLN replacement board in the same way, with the spacers, and reconnect the 3 connectors., PC, MA, MB. That’s it. Will run any game of the Recel system III series: Alaska. Black Magic 1 or 4 players. Cavalier. Crazy Race. Don Quijote. Fair Fight. Hot & Cold. Mr Doom. Mr Evil. Poker Plus. The Flipper Game. Screech. Swashbuckler. Torneo.
avail qty: 7
This chip is dedicated to display and keyboard control. On Gottlieb system 1 CPU board this component is responsible for display control.
avail qty: 1
This spider chip is a peripheral component for PPS4/2 systems. It is a combo: On Gottlieb system 1 CPU board this component is responsible for solenoids control. This device's companion chip is the A1752-EF.
avail qty: 9
This spider chip is a peripheral component for PPS4/2 systems. It is a combo: On Gottlieb system 1 CPU board this component is responsible for the switch matrix management. This device's companion chip is the A1753-EE.
avail qty: 8
This spider chip is a peripheral component for PPS4/2 systems. It is a combo: On Gottlieb system 1 CPU board this component is responsible for solenoids control. This device's companion chip is the A1752-CF.
avail qty: 10
This spider chip is a peripheral component for PPS4/2 systems. It is a combo: On Gottlieb system 1 CPU board this component is responsible for the switch matrix management. This device's companion chip is the A1753-CE.
avail qty: 8
This spider chip is a peripheral component for PPS4/2 systems. It is a combo: On Gottlieb system 1 CPU board this component is responsible for solenoids control. This device's companion chip is the A1752-CE.
avail qty: 10
This spider chip is a peripheral component for PPS4/2 systems. It is a combo: On Gottlieb system 1 CPU board this component is responsible for the switch matrix management. This device's companion chip is the A1753-CD.
avail qty: 10
Thank you for your generosity
avail qty: 9822
Refurb Gottlieb system 1 Control Board 100% tested OK
Out of stock
You want to build your own A175x-yy by yourself? All you have to do is to download the bom and vhdl material and purchase the pcb. Then take your solder station and go.
Out of stock
Thank you for your generosity. This will help us making more and better clones for your machines
